Audio Technica AT95E Cartridge with Elliptical Stylus

Audio Technica AT95E Cartridge with Elliptical Stylus
  • Click to enlarge

£36.00 £29.95


Product Information
Specification
  • Original Audio Technica AT95E Cartridge with Elliptical Stylus
  • Top Performing Budget HiFi Cartridge with Proven High Quality Performance
  • Fitted with an Elliptical Stylus
  • Supplied with Screws and Data Sheet
  • New Unused from Authorised Audio Technica UK Reseller



Audio-Technica  AT95E Phono Cartridge Specifications



Output voltage at 1000 Hz,  5cm/sec.               3.5 mV

Channel balance                                                    within 2.0 dB

Channel separation at 1 kHz                                > 20 dB

Frequency response                                             20-20.000 Hz

Dynamic compliance (x10-6 cm/dyne)              6.5

Static compliance (x10-6 cm/dyne)                    20

Load resistance                                                      47 kOhms

Load capacitance                                                   100 - 200 pF

Stylus type                                                               0.4 x 0.7 mil elliptical diamond stylus

Tracking force range                                              1.5 -2.5 g

Tracking force, recommended                             2.0 g (20 mN)

Vertical tracking angle                                           20°

Coil impedance at 1kHz                                         2.8 K Ohms

Coil inductance at 1kHz                                         400 mH

Recommended load resistance                            47 K Ohms

 Cartridge colour, body/stylus                              Black/Green

Cartridge weight                                                      6.5 g

Dimensions (mm)                                                    L 30.5 x W 17.0 x H 17.20 mm

Replacement stylus unit                                       ATN95E

































Product Code AT95E
Condition New
Weight 0.03kg
