Audio Technica AT VMN95E Elliptical Stylus

Audio Technica AT VMN95E Elliptical Stylus
  • Click to enlarge
  • Click to enlarge

£29.99


Product Information
Specification
  • Original Audio Technica ™ AT-VMN95E  Diamond Elliptical Stylus
  • New Unused from Authorised Audio Technica UK Reseller
  • FEATURES::
  • CORONOVIRUS ISSUES...FROM 12/4/2020 we will be removing these styli and protector from the new  AT cartridges we have in stock as we have run out of individual styli.

  • About the Cartridge  (not included)  .......The AT-VM95E, the new Audio-Technica entry model Elliptical cartridge will replace the legendary AT95E and take advantage of the developments of the AT95EX introduced in 2015. The AT-VM95E features an improved and distinctive design resulting in a more rigid low resonance housing, and two threaded inserts in the cartridge body enabling it to be mounted to the headshell or on an integral tonearm with just two screws, no nuts.

  • Aluminium cantilever
  • 4.0mV output voltage
  • Compatible body with all VM95 Series stylus assemblies
  • Replacement for AT95E and AT95EX
  • 20 to 22,000Hz frequency response
  • SPECIFICATIONS~:

Model

AT-VMN95E

Type

VM Stereo Dual Magnet

Mounting

1/2” centres

Frequency Response

20 - 22,000 Hz

Channel Separation

20 dB (1 kHz)

Output Channel Balance

2.0 dB (1 kHz)

Output Voltage

4.0 mV (@ 1 kHz, 5 cm/sec)

Vertical Tracking Angle

23°

Vertical Tracking Force Range

1.8 - 2.2g (standard 2.0 g)

Stylus Shape

Elliptical

Stylus Size

0.3 x 0.7 mil

Stylus Construction

Bonded Round Shank

Cantilever

Aluminium Pipe



Static Compliance

17 x 10 – 6 cm / dyne

Dynamic Compliance

7 x 10 – 6 cm / dyne (100 Hz)



Replacement Stylus

AT-VMN95E





Product CodeVMN95E
ConditionNew
Weight0.02kg
