Audio Technica AT VMN95SP stylus for 78RPM Records

Audio Technica AT VMN95SP stylus for 78RPM Records
  • Click to enlarge

£49.99


Product Information
Specification
  • Original Audio Technica ™ AT-VMN95SP Diamond 78RPM (only) conical  Stylus
  • New Unused from Authorised Audio Technica UK Reseller
  • FEATURES::
  • DUAL MOVING MAGNET MONO/STEREO CARTRIDGE

    Standard model with a conical / spherical stylus. .

  • About the VM95 series 78rpm SP cartridge (not included)

    Since SP records have monaural modulation, when combining an SP stylus with a stereo body, such as the AT-VM95SP, it is recommended to use the “MONO ON” function “ of your standard Stereo Phono Preamplifier to minimize record surface noise.

    AT-VM95SP, as stereo cartridge for SP mono records, when used with a dedicated archiving phono preamplifierequalizer incorporating various functions to generate a mono signal from Stereo inputs (Mono L+R, Mono L, Mono R, LR Variable Mix) allows professional archivers to minimize noise and distortion by sampling the least damage side of the grooves from an old record.

  • 3mil SP stylus for reduced record surface noise
  • Aluminium cantilever
  • 2.7mV output voltage
  • Compatible body with all VM95 Series stylus assemblies
Modelfor AT-VM95SP
TypeVM Stereo Dual Magnet
Mounting1/2” centres
Frequency Response20 - 20,000 Hz
Output Channel Balance1.5 dB (1 kHz)
Output Voltage2.7 mV (@ 1 kHz, 5 cm/sec)
Vertical Tracking Angle23°
Vertical Tracking Force Range4.5 - 5.5g (standard 5.0g)
Stylus ShapeSP 3 mil Conical Bonded
Stylus Size3 mil
Stylus ConstructionBonded Round Shank
CantileverAluminium Pipe

Static Compliance12 x 10 – 6 cm / dyne
Dynamic Compliance2 x 10 – 6 cm / dyne (100 Hz)

Replacement StylusAT-VMN95SP

Product CodeVMN95SP
ConditionNew
Weight0.03kg
